PBA Systems August 2013 Newsletter

In this Edition:

Product Updates

    • NEW! PDDR150-T Direct Drive Rotary Motor
    • NEW! PSM Shaft Linear Motor
    • NEW! PIX Iron Core Linear Motor
    • PBA Systems Motor Sizer v4.23 Now Available in English and Chinese Language
      CE Mark on All DX B Series Ironless Linear Motors
    • DX A Type Linear Motor – Obsolete

Case Studies

    • Coater/Laminating Machine for Touch Panel
    • Laser Cutting Machine

Events & Other News

    • PBA Systems Participates in Taipei Int’l Industrial Automation Exhibition 2013

Product Updates

NEW! PDDR150-T Direct Drive Rotary Motor

Due to its slim design, the PDDR150-T provides a cost effective solution with high space efficiency. Its flange type design enables operation from the top of the motor. And it also gives the advantages of steady motion in constant speed and smooth rotation due to zero cogging. Other features include:

  • Outer diameter Φ150mm & Inner rotor type
  • Center hole: Φ28mm
  • Max torque: 4.2Nm
  • Resolution: 655,360ppr ~ 4,194,304ppr
  • Slim structure: height 45mm (including flange)
  • High precision model: run-out 5㎛
  • High precision control enabled by optical encoder

For detailed specifications, please visit: http://www.pbasystems.com.sg/products/direct-drive-rotary-motor-modules/pddr-direct-drive-rotary-motor-module/70-pddr-150-t-direct-drive-rotary-pba-systems.html.

PDDR150-T Rotary Motor

NEW! PSM Shaft Linear Motor

PBA Systems introduces the new PSM Series Shaft Motor which features:

  • Compact and rigid design
  • Big clearance for easy installation
  • Ideal for high precision linear motion systems
  • No contact, no cogging, smooth motion
  • High efficiency and high continuous force

For detailed specifications, please visit: http://www.pbasystems.com.sg/products/shaft-linear-motor-modules/psm-shaft-linear-motor-pba-systems.html.

PSM Shaft Linear MotorPSM Shaft Linear Motor
PSM Shaft Linear Motor

NEW! PIX Iron Core Linear Motor

The new PIX Series Iron Core Linear Motor features:

  • Very high force output
  • Compact design
  • High structural rigidity
  • Low cogging force
  • Large air gap for easy installation

For detailed specifications, please visit: http://www.pbasystems.com.sg/products/iron-core-linear-motor-modules/pix-iron-core-linear-motor-module.html..

PIX Iron Core Linear Motor

PBA Systems Motor Sizer v4.23 Now Available in English and Chinese Language

PBA Systems Motor Sizer

You can download the latest version of the PBA Systems Motor Sizer software in both English and Chinese Language from the Downloads section of the PBA Systems website.

PBA Systems Motor Sizer

CE Mark on All DX B Series Ironless Linear Motors

The CE mark can now be found across the entire line of DX B Series Ironless Linear Motors – a sign of PBA Systems’ unwavering commitment to deliver quality products to our customers.

PBA Systems Motor Sizer

DX A Type Linear Motor – Obsolete

PBA Systems would like to regretfully inform our customers that production of all DX A type linear motors will cease effective November 1, 2013. 15 years after it was first launched, the DX A linear motor is now obsolete. It’s replacement, the DX B Ironless Linear Motors has slightly different motor coil dimensions, with the advantage of a longer effective stroke. The magnet track dimensions and mounting holes remain the same.

The diagram below illustrates the differences between the DX A and DX B motor coils. Complete specifications of the DX B Series Ironless Linear Motors are available at http://www.pbasystems.com.sg

DX A vs DX B Series

Case Studies

Coater/Laminating Machine for Touch Panel

The coater machine functions include: dispensing a seal frame, coating glue, precise bonding and solidification.

Normally, dispensing the seal frame comes first, which is a time-consuming step, then followed by the coating glue. However, this machine combines two dispensers and one coater, so it can process two materials at the same time and reduce the dispensing time.

The dispenser part has two axes (X and Y), and the coater part has one axis (X), all using PBA Systems DX B Ironless Linear Motors. The two X-axes were combined into one long X-axis.

Two Dispensers
X-axis: DX30B-C3S
Y-axis: DX30B-C2SOne Coater
X-axis: DX30B-C4S

Touch Panel

Laser Cutting Machine

This machine is used for cutting metal plates. Depending on the customers’ requirements, this machine can be used to cut different patterns.

This machine requires high repeatability, high accuracy, and high acceleration motion profile with low velocity ripple. In order to achieve a high resolution laser cutting head, PBA Systems designed a H-shape gantry which uses DX B Ironless Linear Motors coupled with PBA Systems MaxTune Servo Drive. The MaxMotion Control Card, together with a 0.5 um resolution encoder, was used to coordination and synchronization of the demanding motion profile .

Laser Cutting Machine

Events & Other News

PBA Systems Participates in Taipei Int’l Industrial Automation Exhibition 2013

For the fourth year in a row, PBA Systems will again participate in the Taipei Int’l Industrial Automation Exhibition to be held at the Taipei World Trade Center NanGang Exhibition Hall on August 28- 31, 2013.

Tapei International Industrial Automation Exhibition

The annual trade event exhibits the latest in manufacturing automation technologies with thousands of visitors and participants from all over the world. To get a first hand look at our products, you are welcome to visit our product distributors’ booths at:

Secsuyo: booth K916 (1F) and
Aurotek: booth J918 (1F)

For more information about the event, visit the exhibition website at http://www.autotaiwan.com.tw/en/.
