Renishaw Encoder

Linear and rotary position measurement at low cost, with high reliability and capable of operating in harsh environments.

    • Incremental and absolute position measurements are available
    • The non-contact design ensures no mechanical wear
    • Robust magnetic position sensing technology provides excellent resistance to most forms of contamination
Category: Tag:

Renishaw is one of the world’s leading engineering and scientific technology companies, with expertise in precision measurement and healthcare. The company supplies products and services used in applications as diverse as jet engine and wind turbine manufacture, through to 3D printing, dentistry and brain surgery.
The Renishaw Group currently has 80 offices in 36 countries, with over 4,500 employees, of which around 3,000 people are employed within the UK. For the year ended June 2019 Renishaw achieved sales of £574 million, of which 94% was due to exports. The company’s largest markets are the USA, China, Japan and Germany.

QUANTiC encoder series

The QUANTiC encoder system integrates Renishaw’s filtering optics design and interpolation technology to create a super-compact, robust, incremental open optical encoder. QUANTiC encoders are easy to use with exceptionally wide installation and operation tolerances, along with built-in calibration functions.

QUANTiC readheads offer digital output and a new analogue output variant with a wide variety of configurations and linear or rotary scale options. Speeds up to 24 m/s can be achieved to meet the most demanding motion control requirements.

Detailed diagnostic information can be accessed by using the Advanced Diagnostic Tool ADTi‑100 and ADT View software during installation or for in-field diagnostics and fault finding.

For more information, please visit: https://www.renishaw.com/en/quantic-encoder-series–43210





ATOM encoder series

ATOM is Renishaw’s miniature non-contact optical incremental linear and rotary encoder system. Its innovative design combines miniaturisation with leading-edge signal stability, dirt immunity and reliability. This combination is unique in the market place and represents a significant advance in the performance and reliability of miniature encoders.

ATOM systems are simple to install with integrated LED for signal integrity indication.

A range of interfaces is available including high-performance Ti, Ri and the compact PCB ACi interface.



For more information, please visit: https://www.renishaw.com/en/quantic-encoder-series–43210

VIONiC encoder series

The VIONiC encoder series is Renishaw’s highest performing incremental optical encoder. It provides direct digital position feedback with superior metrology, fast speeds and high reliability. The VIONiC readhead integrates Renishaw’s market proven filtering optics and advanced interpolation technology. This provides ultra‑low Sub-Divisional Error (SDE), excellent dirt immunity, and eliminates the need for additional adaptors or separate interfaces.

VIONiC readheads are compatible with a wide range of linear, partial arc and rotary scales, from low expansion ZeroMet, to high accuracy REXM rings. This makes it a versatile product suitable for a wide variety of applications, where metrology cannot be compromised.

Designed with intuitive auto-calibration mode, VIONiC readheads are easy to install. An optional Advanced Diagnostic Tool ADTi-100 is available for real‑time encoder data feedback during installation or for in-field diagnostics.

For more information, please visit: https://www.renishaw.com/en/vionic-encoder-series–38973
